Self-supporting Dielectric Optical Cables for spans up to 100 meters are used for optical junctions in urban networks or access in subscriber networks. All dielectric self-supported cable up to 12 fibers with small size, light weight and convenient installation.
Product type: ASU
Application: Urban networks or access in subscriber networks communication network
Product description:
ASU optical cable (non-metallic strength member, three elements twisted, dry water blocking material, polyethylene jacketed outdoor optical cable) adopt optical fibers into single loose tube made of high modulus plastic filled with waterproof compound, which is twisted with two non-metallic strength members, and a layer of polyethylene is extruded outside.
Laying mode: External/Outdoor Self-Supported installation
Operating temperature:-20℃～+65℃
|
Cores |
Minimum bending radius（mm） |
Allowable tensile force（N） |
Allowable crush resistance （N/100mm） |
|
|
static |
dynamic |
|||
|
2～12 |
10D |
20D |
1.5 * cable weight * g |
1000 |
Note: D means the outer diameter of the optical cable
1、Low transmission loss and dispersion.
2、Precise fiber excess length control ensures excellent tensile and temperature performance of optical cable.
3、The loose tube material has good hydrolysis resistance, and the tube is filled with fiber gel to protect the optical fiber
4、All dielectric optical cable, especially suitable for self-supporting overhead line around electric field or lightning prone area, with span distance less than 100m.
